Respicefinem High Performance 200mm Stroke Linear Rail Guide Slide Actuator with T6x1 Screw and 28 Stepper Motor for Linear Stage Motion
Product details
| Management number | 220414068 | Release Date | 2026/05/03 | List Price | $17.75 | Model Number | 220414068 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Item Type: Linear Rail Guide Slide ActuatorMaterial: Aluminum AlloyEffective Stroke: 200mm (The distance that the slider can move on the slide is 200MM)Screw Specification: T6x1Screw: T6Pitch: 1 (Rotate the motor once, the distance the slider moves on the screw is 1mm)Screw Accuracy: ±0.01mmLoad: Horizontal 5KG; Vertical 1KGPositioning Accuracy: ±0.1mmHolding Torsion: 6N.cmCurrent: 0.6A: 5.5ΩInductance: 3.2MHSpeed: 0-120mm/sStep Angle: 1.8 degreePackage List：1 x Linear Rail Guide Slide Actuator
- Screw Specification: The actuator features a T6x1 screw with a pitch of 1 It means rotating the motor once moves the slider 1mm on the screw with an accuracy of ±0.01mm
- Load Capacity: It can handle a horizontal load of up to 5KG and a vertical load of up to 1KG
- Positioning Accuracy: Offers a positioning accuracy of ±0.1mm ensuring precise linear motion
- Holding Torsion: Comes with a holding torsion of 6N.cm providing stable operation
- Performance Parameters: Operates at a current of 0.6A with a of 5.5Ω and inductance of 3.2MH. Its speed ranges from 0 - 120mm/s and has a step angle of 1.8 degree
| Color | #511 |
|---|---|
| Brand Name | Respicefinem |
| Manufacturer | Respicefinem |
| Model Number | Respicefinem2kigdy6pvt |
| Item Type Name | Linear Motion Lead Screws |
| Number of Items | 1 |
| Included Components | No |
| Manufacturer Part Number | Respicefinem2kigdy6pvt |
